Extech 382276 600W开关模式直流电源

  • 制造商: EXTECH
    Model: 382276
    来源: China
    • 报价要求 报价要求
  • Price (exclude tax) 7,426,000 VND
    Price (include tax) 8,168,600 VND
  • 现货: 1
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Output Voltage (Res.): 1 to 30V (100mV)

Output Current (Res.): 1 to 20A (100mA)

Basic accuracy: ±(0.5%+2 digits)

Load Voltage Regulation: 50mV

Line Voltage Regulation: 20mV

Load Current Regulation: 100mA min

Line Current Regulation: 50mA min

Ripple and Noise: <5mVrms

Power: 230V, 50Hz/60Hz

Dimensions 7.9 x 3.5 x 8.5" (200 x 90 x 215mm)

Weight 5.7lbs (2.6kg)

Complete with power cord

Details

Features:

  • Overload, over-temperature, and short circuit protection
  • Remote Control for output Voltage/Current and On/Off
  • Two user-defined Voltage and Current presets and one 13.8V/20A factory preset
  • Automatic Constant Current crossover
  • High RFI immunity and excellent EMI
  • Thermostatic Control Fan from zero to full speed
  • Dual 3-Digit LED displays
