- Pin Moisture Via External Probe Range
+ Wood groups 1-9:
1-5: oak, most maples, pine, hickory, teak, sycamore
6-9: building materials: plywood, drywall, OCD 7% - 30%, 30 % - 100%; ±1.5% (reference only)
+ Construction material groups:
10: brick, cement screed, concrete
11: cement mortar, anhydrite screed, lime mortar, plaster: 0- 20% (reference only)
- Pinless Moisture Range: 0–100 relative measurement
- Pinless Moisture Depth: 1.9cm (0.75”) maximum
- Sample Rate: 10Hz (approx., both modes)
- Measurement Resolution: 0.1
- Response Time Pinless: 100 ms
- Response Time Pin Mode: 750 ms
General Information
- Display type (W × H): QVGA (320 × 240) pixel 2.3” 64K color TFT graphical display
- Stored Data File Format: Comma Separated Values (.csv) format with date/time stamp. Reading value, reading type included
- Saved Image File Format: Bitmap (.bmp) with measurement values overlaid
- Stored Image Capacity: 9999 images
- Internal Memory: 4GB
- Certification Standards: EN61326 (EMC), EN61010 (Battery + Charger)
- Agency Approvals: FCC Class B, CE, UL
- Power Requirements: Integrated rechargeable battery
- Continuous Run Time: 18 hours max
- Typical Usage: 4 work weeks
- Auto Power Off: Programmable: OFF, 1, 5, or 20 minutes
- Power Adapter: 100–240 V input/ 5 V 1A output
- Battery: 3.7 V, 3000mAh Li-ion rechargeable via micro USB
- IP Rating/Drop Test: IP54/3m (9.8 ft)
- Operating Temperature: 0~50 °C (32~122 °F)
- Storage Temperature: -10~60°C (14~140°F)
- Operating Humidity: ≤ 90%, 0~30°C (32~86°F)
≤ 75%, 30~40°C (86~104°F)
≤ 45%, 40~50°C (104~122°F)
- Storage Humidity: 90% RH
Unit included
- Moisture Meter
- MR02 Pin Probe
- Quick Start Guide
- International Charger
Optional accessories
- MR04 Extension Pole
- MR05 Impact Pin Probe
- MR06 Wall Cavity Probe
- MR07 Hammer Probe
- MR08 Hammer and Wall Cavity Probe Combo
- MR09 Baseboard Probe
- MR10 Protective Case
