Wireless frequency: 2.4 GHz (10m)
DCV: 0.1 mV ~ 1000 V /0.25 %
ACV: 0.1 mV ~ 1000 V /1.0 %
DCA: 1 mA ~ 10 A /1.0 %
ACA: 1 mA ~ 10 A /1.5 % + 3
R: 0.1 Ω ~ 40 MΩ
C: 1 nF ~ 9999 μF
F: 5 Hz ~50 kHz
T (type K):-40 °C ~ +400 °C
Power: AA batteries
AC true-rms: yes
Auto/Manual: yes
Backlight: Yes
Min/Max/Avg: Yes
Removable display: Yes
Size:5.3 cm x 9.3 cm x 19.3 cm
Weight: 604 g (1.3 Ib)
Includes:Test Lead Set, Alligator Clip Set, 80BK-A Temperature Probe, CD-ROM, Users Manual, 5xAA Batteries
Details
| Accuracy specifications |
| DC voltage |
| Range |
0.1 mV to 1000 V |
| Accuracy |
0.25 % + 2 |
|
| AC voltage |
| Range |
0.1 mV to 1000 V |
| Accuracy |
1.0 % + 3 |
|
| DC current |
| Range |
1 mA to 10 A |
| Accuracy |
1.0 % + 3 |
|
| AC current |
| Range |
1 mA to 10 A |
| Accuracy |
1.5 % + 3 |
|
| Resistance |
|
| Counts |
|
| Capacitance |
| Range: |
1 nF to 9999 μF |
| Resolution: |
1nF |
|
| Frequency |
| Range: |
5 Hz to 50 kHz |
| Resolution: |
0.01Hz |
|
| Temperature |
|
| Power |
| |
AA batteries: Three for main body; two for display |
|
| Battery life |
|
| Wireless frequency |
| |
2.4 GHz ISM Band 10 meter range |
|
| Safety rating |
| |
CAT IV 600 V , CAT III 1000 V |
|
| General specifications |
| Basic features |
| AC true-rms |
Yes |
| Ranging |
Auto/Manual |
|
| Display |
|
| Data storage |
|
| Other features |
| Battery type |
AA alkaline |
| Removable display |
Yes |
|
| Warranty and protection |
| Safety rating |
CAT IV 600 V/CAT III 1000 V |
| External protection |
Rubber overmold |
| Warranty |
|
| Size (H x W x L) |
5.3 cm x 9.3 cm x 19.3 cm (2.08 in x 3.6 in x 7.6 in) |
| Weight |
604 g (1.3 Ib) |
|
