FLUKE 375 钳形表 (600A; True RMS)

ACA jaw: 600A /0.1 A /2% ± 5 digits

ACA iFlex (optional): 2500A /0.1 A /3%  ± 5 digits

DCA: 600A /0.1 A/ 2% ± 5 digits

ACV: 600V /0.1 V /1.5% ± 5 digits

DCV: 600V /0.1 mV /1% ± 5 digits

R: 60,000 Ω /0.1 Ω /1% ± 5 digits

F: 500 Hz /0.1 Hz /0.5% ± 5 digits

C: 1 µF to 1000 µF /1 µF /1% ± 4 digits

True-RMS: yes

Continuity : yes

Hold: yes

Backlight : yes

Min/Max/Avg : yes

Inrush : yes

Diameter conductor: 1.3" or 34 mm max

Size: 10.905 x 3.464 x 1.629 in (277 x 88 x 43 mm)

Weight: 12 oz. (350g)

Included:  Coated instruction card, Safety information sheet, Soft carrying case , TL75 test leads, Two

Detail

Features and benefits

  • iFlex flexible current probe expands the measurement range to 2500 A ac while providing increased display flexibility, ability to measure awkward sized conductors and improved wire access.
  • CAT IV 600 V, CAT III 1000 V
  • True-rms ac voltage and current for accurate measurements on non-linear signals
  • 500 mV dc measurement range to interface with other accessories
  • Integrated low pass filter and state of the art signal processing allows for use in noisy electrical environments while providing stable readings
  • Proprietary inrush measurement technology to filter out noise and capture motor starting current exactly as the circuit protection sees it
  • Ergonomic design fits in your hand and can be used while wearing protective equipment
  • Large, easy to read backlight display automatically sets the correct measurement range so you do not need to change the switch positions while taking a measurement
  • Three-year warranty
  • Soft carrying case

Safety conformance
EN/IEC 61010-1:2001; 1000V CAT III, 600V CAT IV

What’s the difference between the clamp meter models?

  Fluke-365 Fluke-373 Fluke-374 Fluke-375 Fluke-376 Fluke-381
Measure ac current 200.0 A 600.0 A 600.0 A 600.0 A 999.9 A 999.9 A
Measure ac current via iFlex     2500 A 2500 A 2500 A 2500 A
Measure ac voltage 600.0 V 600.0 V 600.0 V 600.0 V 1000.0 V 1000.0 V
Measure continuity ≤ 30 Ω ≤ 30 Ω ≤ 30 Ω ≤ 30 Ω ≤ 30 Ω ≤ 30 Ω
Measure dc current 200.0 A   600.0 A 600.0 A 999.9 A 999.9 A
Measure dc voltage 600.0 V   600.0 V 600.0 V 1000.0 V 1000.0 V
Measure resistance 6,000 Ω 6,000 Ω 6,000 Ω 60k Ω 60k Ω 60k Ω
Measure frequency       500 Hz 500 Hz 500 Hz
Measure inrush     100 mS 100 mS 100 mS 100 mS
Work in poorly lit areas Backlight Backlight Backlight Backlight Backlight Backlight
Measure non-linear loads True-rms True-rms True-rms True-rms True-rms True-rms



374/375 Data Sheet »
