After flame time: 0-999.9s resolution 0.01s
After glow time: 0-999.9s resolution 0.01s
Burning time: 12s (adjustable)
Nozzle:
Inner diameter: 10^-0,5mm
Angle: 90°C
Dimension of specimen holder
Out frame: 442*76*12.5mm
Inner frame: 356x51mm
Testing flame height: 38mm
Distance between nozzle top and specimen: 19mm
Tearing weights: 100g, 200g, 300g, 475g
Power supply: AC 220V 50/60hz
Dimensions: 600x450x885mm (LxWxH)
Weight: 44kg
Standards: ASTM D6413
Standards accessories: 4 x Tearing weights, 1 x Air supply device, 1 x Sample holder, 1 x Flame measuring scale, 1 x Power line
Optional accessories: Φ11mm Nozzle, Φ10mm Nozzle, CFR1615,1616 holder and tear weights, ASTM D6413 holder and tearing weights, CALIF TB-117 holder
