GESTER GT-KC13B-8 磨蚀试验器 (8 warking stations)

Used to determine the abrasion resistance of all kinds of footwea Working station: 8

Control mode: Touch screen control

Abradant table:  ≥ ¢125mm

Lissajous figure: 60±1 mm x 60±1 mm

Test Pressure:

A) Specimen holder: (198 ±2)g

B) Larger loading piece: (597±5)g

C) The sum mass: (795±7)g, for workwear, upholstery, bed linen  and fabrics for technical use ( nominal pressure of 12kpa)

A) Specimen holder: (198 ±2)g

B) Smaller loading piece: (397±5)g

C) The sum mass: (595±7)g, for apparel and household textiles,  excluding upholstery and bed linen (nominal pressure of 9kpa)

Exposed area of specimen holder: 645 ± 5 mm2

Rotational Speed: 47.5 ± 2.5 r/min

Pressing Weight:

Mass : (2.5 ± 0.5) kg

Diameter: Φ(120 ± 10) mm

Dimensions ( L x W x H ): 88×78*37cm

Weight: About 160kg
