GW Instek GSP-730 is a 3 GHz Spectrum Analyzer mainly developed to fulfill the demands of RF Communication educations. Budget constraint and insufficient teaching tools are normally the two hurdles for schools to provide high-quality courses for RF communication experiments. A moderate spectrum analyzer, GSP-730, featuring full functions should provide, along with GRF-1300 training kit possesses a unique position in the field as an economic turn-key solution for 3GHz RF Communication Experiment courses.
With its components, GSP-730 Spectrum Analyzer, GRF-1300 Trainer and a PC, properly connected, a tangible system is integrated for performing ongoing experiments while the lecture is given. Using a PC, the teacher can present teaching material with PowerPoint slide and simultaneously control GSP-730 and GRF-1300 to perform experiments and get spectrum displays and parameter readings on the PC screen. GSP-730 and GRF-1300 easily transferred the current teaching materials, including the PowerPoint slides, textbook, and a remote control software, into electronic-teaching system.
Fully-electronic RF training system
The combination of GSP-730 and GRF-1300 forms a fundamental training system for RF communication and telecommunication classes in the universities, colleges, vocational schools, and the training centers in military as well as private companies. Instead of the tremendous cost of the installation of new training system, the conjunction of GSP-730 and GRF-1300 provides an economic solution to eliminate two obstacles, budget constraint and insufficiency of teaching tools.
unctionItemSpecificationBase BandWaveformsSine, Square, TriangleFrequency Range0.1~3MHz
Step: 10kHzAmplitude≧1.5VppHarmonics Distortion≦-30dBcRF/FM GeneratorFrequency Accuracy±0.15MHzAdjustable Range≧45MHz (870M ~ 920MHz)
Step: 1MHzPower Range≧-15dBmFMMax Frequency Deviation>3MHzAMPeak Difference≧-18dBmInterface USB DeviceDimensions & Weight 165(W)*155(H)*90(D)mm, 1.2kg
Quick Start manual *1, User Manual CD *1, Power Cord *1
Experiment test book of student version, Power point file and remote control software CD, RF Cable *3, Antenna *1, N to SMA adaptor connector, Power Cord *1
Experiment text book of teacher version
PC Software Remote Monitor Software
