GW intek PSB-1800L 可编程多量程台式开关直流电源

 Specification:

OUTPUT  RATING:

Output voltage(V): 0~40

Output current(A): 0~80

Output power(W): 800W

REGULATION (CV):

Load regulation (mV): 25

Line regulation (mV): 23

REGULATION (CC):

Load regulation (mA): 85

Line regulation(mA): 85

RIPPLE & NOISE (Noise Bandwidth 20MHz ; Ripple Bandwidth = 1MHz)

CV p-p: 80

CV rms: 11

CC rms: 160

PROGRAMMING ACCURACY:

Voltage: 10      0.1% +

Current:  40     0.1% +

MEASUREMENT ACCURACY:

Voltage: 10      0.1% +

Current: 40      0.1% +

RESPONSE TIME:

Raise Time: 50

Fall Time(Full load): 50

Fall Time(No load): 500

Load Transient Recover Time(Load change from 50 to 100%): 1

PROGRAMMING RESOLUTION (By PC Remote Control Mode):

Voltage: 1

Current: 2

MEASUREMENT RESOLUTION (By PC Remote Control Mode):

Voltage: 1

Current: 2

SERIES AND PARALLEL CAPABILITY:

Parallel Operation: Up to 4 units including the master unit

Series Operation: Up to 2 units including the master unit

PPROTECTION FUNCTION:

OVP: 4-44

OCP: 5-88

OHP: Turn the output off.

FRONT PANEL DISPLAY ACCURACY, 4 digits:

Analog Control: Yes

Interface: USB/LAN/GPIB(Option)

Power Source: 100Vac to 240Vac, 50Hz to 60Hz, single phase

Dimension & Weight: Approx. 6.8kg  214×124×350
