GW INSTEK PEL-3533 可编程直流电子负载 (1.5V~150V, 0~1050A, 5250W)

Voltage: 1.5V~150V
Current    0~1050A
Power    5250W
Operating Range     0~1050A; 0~105A
Accuracy of Setting: ±(0.2 % of set + 0.1 % of f.s*1) + Vin*2/500 kΩ
Constant Resistance Mode
   Operating Range: 700.008S~12mS (1.42855mΩ~83.3333Ω)
             70.0008S~1.2mS (14.2855mΩ~833.333Ω)
    Accuracy of Setting  ±(0.5 % of set*4 + 0.5 % of f.s.*3) + Vin*2/500 kΩ
    Resolution: 12mS; 1.2mS
Constant Voltage Mode:
   Operating Range: 1.5V~150V/  1.5V~15V
   Accuracy of Setting: ±(0.1 % of set + 0.1 % of f.s)
   Resolution    10mV / 1mV
Constant Power Mode:
  Operating Range:525W~5250W/ 52.5W~525W
  Accuracy of Setting: ±(0.6 % of set + 1.4 % of f.s*3)
  Resolution    500mW; 50mW
Voltmeter      Accuracy     ±(0.1 % of rdg + 0.1 % of f.s)
Ammeter    Accuracy    ±(0.2 % of rdg + 0.3 % of f.s)
Power Source    AC100V ~ 230V±10% ; 50Hz / 60Hz ± 2Hz
Interface    USB/RS232C/Analog Control (Standard) ; GPIB(Option)
Weight     Approx. 96.5 kg
DIMENSIONS & WEIGHT    598(W)x611(H)x706(D)mm
