Electrical data: 220V 50HZ
Temperature Range: RT+10-250°C
Temperature Resolution: 0.1°C
Temperature Uniformity: ±3% (At 100°C)
Chamber dimension (mm, W*D*H): 340*325*320
External dimension (mm, W*D*H): 620*540*490
Timer Range: 1-9999minutes
1. Intelligent programmable temperature LCD controller.
1. Independence temperature limited alarm system.
2. RS484 connector and communication software.
3. Control board and printer (Build-In or Independence printer)
4. 25mm test port.
4. U Disk store system.
1. With mirror surface in stainless steel, Foursquare semicircle transition, shelf support handing freely, easy for cleaning within the case.
2. It adopts temperature control protection, digital display, microcomputer PID temperature controller with the timer function to ensure precise and reliable temperature control.
3. Hot air circulation system is composed of the blower fan and proper air channels, which is capable of continuous operation at high temperature. Improve the uniformity of the temperature inside the working chamber.
4. New-style Silicon gasket ensures long-life under high temperature, and easy to replace.
5. Can adjust the flow of blast & exhaust in control panel.
6. Independent alarm system for temperature-limiting ensures experiments run safely and no accident would happen.(Option)
7. Recorder and printer are options which can print or record-setting parameters and trace variation curves of temperature(4~20mA standard signal).(Option)
