Hopetech CHT8000 数据记录仪(8通道/卡,420V AC - 600V DC)

Manuafacturer: Hopetech
Model : CHT8000
Origin: China
Warranty : 12 month

-Display: 4.3 inch TFT LCD
-Number of Channels: 8 channels/card
-Temperature Sensor:
 +TC: B,E,J,K,S,T,N, R
 +RTD: Pt100, Pt1000, Cu50
-Temperature Resolution: 0.1°C
-Test  Accuracy: 0.2%+0.5°C
-Signal Range:
 + DCV: 50mV/500 mV /5V
 + DCI: 0~20mA
- Max Reading:
 + DCV: 50000
 + DCI: 2000
- Signal Accuracy: 0.2%
- Input Impedance: 1MΩ
- Channels Isolation: 420V AC - 600V DC
- Sampling Period: 25ms/100ms/250ms
-Recording Period: 25ms/100ms/250ms/1s/2s/5s/10s
-Internal Memory: 60M
-External Storage: U disk(Max 2G)
-Interface: Standard feature: RS232/RS485/USB; Options: Ethernet
-Comparator: Each channel has upper and lower alarm
-Alarm Output: 8channels/card(Optional),custom channels alarm, relay signal output
-Other Functions: cold junction compensation, each channel temperature correct, burnout alarm
-Power Supply: Voltage:90V-242V AC ;  Frequency:47Hz-400Hz
-Maximum Power: 5VA (Meter); 1.2VA (Measuring Card)
-Dimensions: 263mm*249mm*102mm(L*W*H)
-Weight: 2.5kg

Details
CHT800X is a new generation of ARM-based true color paperless recorder. It uses a compact card design, the card can be divided into the capture card, alarm card, arbitrary and can be configured as an independent module, and each card can work in parallel. Acquisition card fully isolated universal input function, with the thermocouple signal, thermal resistance signal, standard voltage signal, standard current signal, you can test the -270 ~ 1300 temperature signal, 0 to 50V voltage signal, 0 ~ 20mA current signal. Capture card can be off-host independent remote testing. The alarm card output custom channel relay alarm signal.

FEATURE
 4.3-inch TFT color LCD display, 48 channels can be displayed simultaneously
 The temperature, current, voltage signal universal input, programmable simultaneous acquisition parameters
 Precision test temperature accuracy can reach 0.5 ° C accuracy of the voltage, current acquisition of up to 0.2%
 The card design, easy to add channels, the host standard six card slots, the maximum number of channels from 48 to 72
 Channel custom alarm settings, optional alarm card output relay alarm signals

Model

CHT8000

CHT8000A

CHT8000B

Display

4.3 Inch TFT LCD Display

Number of Channels

8 channels/card

12 channels/card

8 channels/card

Temperature Sensor

TC: B,E,J,K,S,T,N, R

RTD:Pt100, Pt1000, Cu50

TC: B,E,J,K,S,T,N, R

TC: B,E,J,K,S,T,N, R

RTD: Pt100, Pt1000

Temperature Resolution

0.1°C

0.1°C

0.1°C

Test Accuracy

0.2%+0.5°C

0.2%+0.5°C

0.2%+0.5°C

Signal Range

DCV

50mV/500 mV /5V

50mV/500mV/5V /50V

——

DCI

0~20mA

——

——

Max Reading

DCV

50000

50000

——

DCI

2000

2000

——

Signal Accuracy

0.2%

0.2%

Input Impedance

1MΩ

10MΩ

Channels Isolation

420V AC 600V DC

——

Sampling Period

25ms/100ms/250ms

Recording Period

25ms/100ms/250ms/1s/2s/5s/10s

Internal Memory

60M

External Storage

U disk(Max 2G)

Interface

Standard feature: RS232/RS485/USB

Options: Ethernet

Comparator

Each channel has upper and lower alarm

Alarm Output

8channels/card(Optional),custom channels alarm, relay signal output

Other Functions

cold junction compensation, each channel temperature correct, burnout alarm

Power Supply

Voltage:90V-242V AC  Frequency:47Hz-400Hz

Maximum Power

5VA (Meter)

1.2VA (Measuring Card)

Dimensions

263mm*249mm*102mm(L*W*H)

Weight

2.5kg
