Hopetech HT6611 可编程直流电源 (0-30V, 0-5A)

Output Rating:

    Voltage: 0-30V

    Current: 0-5A

Load Regulation:

    Voltage: <0.01%+0.5mV

    Current: <0.01%+0.1mA

Setting Value Resolution:

    Voltage: 0.5mV

    Current: 0.1mA

Readback Value Resolution:

    Voltage: 0.1mV

    Current: 0.01mA

Setting Value Accuracy:

    Voltage: 0.01%+2mV

    Current: 0.05%+1mA

Readback Value Accuracy:

    Voltage: 0.02%+5mV

    Current: 0.1%+5mA

Ripple:

    Voltage: 3mvp-p

    Current: 2mA rms

Volmeter Accuracy:

    0-12V Accuracy: 0.02%+2mV

    0-58V Accuracy: 0.02%+6mV

Milli ohmmeter accuracy:

    10W. 0-1000mΩ Accuracy: 0.2%+3mΩ

    1000-10000mΩ Accuracy: 0.2%+6mΩ

Working Condition: 0-40°C; 0-90%RH

Power Required: AC 120V/220V±10%; 50/60HZ

Dimension: 358*214*104
