Huatec HG-808A 集成IP65振动计开关振动传感器输出0-5v

Specifications:

- Transverse sensitivity: <5%
- Shell electrical isolation
- Measure parameter: velocity or acceleration, virtual value or acceleration peak value
- Measure range optional: Max 180 ms-2 Or 200mm/s
- Vibrating value voltage outpute: 0-5V
- Frequency Response:
          + 10-1000Hz(velocity,5% accuracy)
          + 1-1000 Hz(acceleration,5% accuracy)
- Working tempreture (℃): -20～70；
- Power supply: 24Vdc；
- Alarm level: 2
- Alarm output: relay touch spot on each level(normally open or close optional)
- alarm value adjustable
- Cable socket Model:(SY)X12KX3P
- Case material: aluminum, sealed
- Extraction: sideway
- Protect grade: IP65
- Sensor install: M8 x 1
- size:Ф40 x 80 mm
- weight: 250g
