HK-1P HUATEC 液晶显示器铅笔硬度计数字内置打印机台式

  • 制造商: HUATEC
    Model: HK-1P
    来源: China
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Specifications:

- Product Type: HK-1M
- Standards Conformed to: <GB/T 26704-2011 Pencil Testing>
- Test force (N): 0.245,0.49,0.98,1.96,2.94,4.98
- Minimum test unit: 0.062µm
- Hardness test range (HK): 40-700
- Test force loading: Automatic (loading, dwell, unloading)
- Indenter and lens converters: Automatic
- Test microscope magnification: 100X (for observation) , 200X (for test)
- Test force dwell time: 0~60s,Recommended 10s
- X-Y Test table: Dimension:100*100mm  Movement:25*25mm
- Data Output: LCD readout display, built-in printer
- The indenter center-outer wall Distance: 95mm
- Power supply: AC220V+5%,50-60Hz
- Dimensions: 405*290*480mm
- Weight: 25Kg


 Standard Accessories:

- Axle weight 1
- Weight 6pcs
- Cross test sets: 1
- Lead holder: 1
- Small Level: 1
- 10X eyepiece test: 1
- Screw driver: 2pcs
- Foot adjustment screw: 4pcs
- Power cable: 1
- Spare fuse (2A): 2pcs
- Product Manual: 1
- Product certification: 1
