HV HIPOT GDFJ-VI Portable Dissolved Gas Analyzer

FID (flame ionization detector)

Detection limit: Mt≤3×10-12g/s (Hexadecane/isooctane)

Baseline noise: ≤5×10-14A

Baseline shift: ≤1×10-13A/30min

Linear range: ≥ 106

TCD (thermal conductivity detector)

Sensitivity: S≥3500mV•ml/mg (conventional); 5000mV•ml/mg (highly sensitive)

Baseline noise: ≤10μV

Baseline shift: ≤30μV/30min

Linear range: ≥104

Temperature control index

Temperature control part: Range

Column box: 4~ 450℃ above room temperature, accuracy ±0.1℃

Packed column injector: 4~ 450℃ above room temperature, accuracy ±0.1℃

FID Detector: 4~ 450℃ above room temperature, accuracy ±0.1℃

TCD Detector: 4~ 450℃ above room temperature, accuracy ±0.1℃

Ni nickel catalyst reformer: 4~ 450℃ above room temperature, accuracy ±0.1℃

Other parameters

Dimension: 420*280*300mm

Weight: <15kg

Power supply: AC220V±10%, 50Hz


Accessories

Name Specification Qty.

Portable DGA: GDFJ-VI x 1 set

Chromatography workstation: Insulating oil special edition x 1 set

Miniature Full Automatic Oscillator:   x 1 set

High Purity Nitrogen: 2L, 99.999%, Aluminum alloy bottled x 2 bottles

High Purity Hydrogen: 2L, 99.999%, Aluminum alloy bottled x 1 bottle

Standard Gas: 2L, 7 Components, Aluminum alloy bottled x 1 bottle
