INSIZE 2186-225 表盘内径规 (200-225mm)

Range: 200-225mm

Parallelism of measuring faces: 10µm

A: 244mm

B: 95-120mm

C: 130mm

Left anvil retracting stroke: 2mm

Measuring force: 6-8N

Flatness of anvil: 1.5µm

Repeatability: 1µm

Carbide measuring faces for anvils

Front edges of anvils are chamfered for easy workpiece insertion

Optional accessory:

- Dial indicators and digital indicators (reading 0.0001mm or 0.01mm)
