INSIZE DHG-C420 1D 手动高度计 (无气垫) (0~406mm; 8μm)

Univeral Measuring range: 0~406mm

Accuracy (at 20°C): 8μm

Repeatablility: 3μm

Resolution: 0.1mm; 0.01mm; 0.001mm (selectable)

Data output: USB

Measuring force: 0.75N; 1N; 1.25N; 1.5N (seclectable)

Power supply: rechargeable battery

Working temperature: 10°C~40°C

Weight: 21kg

Standard delivery:

- Main unit: 1pc

- Φ4mm ruby ball probe: 1pc

- Calibration block: 1pc

- AC/DC adapter: 1pc

- USB cable and software: 1pc

Optional accessory:

- Transmitter: 7306-100

- Receiver: 1306-2

- Probe: DHG-C-C2A; DHG-C-C4A; DHG-C-R4; DHG-C-R5B; DHG-C-R10; DHG-C-CP1
