Measuring range : magnetic induction probe (Fe) 0-2000 µm , eddy current probe (NFe) 0-800µm
Accuracy : ±(1.5+2%L)µm L is measuring thickness in µm
Resolution : 0.1µm (range 100µm) , 1µm (range 100~1000µm) , 10µm (range≥1000µm)
Repeatability : 1µm (range 0~1000µm) , 10µm (range≥1000µm)
Measuring mode : continuous or single
Calibration mode : four points calibration
Minimum substrate thickness : magnetic induction probe (Fe), (NFe): 0.2mm 0.05mm
Minimum measuring area : 5x5mm
Power supply : 2×1.5V AA batteries
Dimension of main unit : 122×65×22mm
Weight of main unit : 150g
STANDARD DELIVERY : Main unit, Battery (AA), Zero calibration block for Fe probe, Zero calibration block for NFe probe
