INSIZE ISU-700D Ultrasonic Thickness Gage (For Thin Workpiece) ((T-E): 1.5-20mm; (E-E): 0.2-10mm)
制造商: INSIZE Model: ISU-700D 保障: 12 Month - 联系
Measuring range:
- Transmit-echo (T-E) mode: 1.5-20mm
- Echo- echo (E-E) mode: 0.2-10mm
Measuring unit: mm/inch
Resolution: 0.1/0.01/0.001mm
Accuracy:
- ±0.04mm (H<9.99mm)
- ±(0.04+0.1%H)mm (H: 10~99.9mm)
- H is the thickness to be measured in mm
Transducer:
- Type: Monocrystal probe
- Frequency: 15.0MHz
- Diameter (Ød): 7.5mm
Display: 320x240, color screen display
Velocity: 1000~9999m/s
Measuring frequency: 2 times/sec and 10 times/sec
Applicable temperature: -20~50oC
Output: USB
Power supply: 2x1.5V AA batteries
Dimension: 133x75x29mm
Weight: 260g (including batteries)
