ITECH IT5101H Battery Tester (-1000~+1000V, 10uV/0.1 uΩ)

- Voltage value:
+ Range -10V~+10V; 20uV; ±(0.01%+0.01%FS)
+ Range -100V~+100V; 0.2mV; ±(0.01%+0.01%FS)
+ Range -1000V~+1000V; 2mV; ± (0,01% + 0,01% FS)
- Resistance value:
+ Range 3000Ω/0.1Ω (0.4% + 0.05% FS)
+ Range 3mΩ/0.1μΩ; ± (0.4% + 0.05% FS)
- Response time: 10ms
- Rated input: DC±300V
- Communication Interface: GPIB/USB/LAN
- Operating Temperature: 0℃~40℃ 80%RH below(No condensation)
- Storage Temperature: -10℃~50℃ 80%RH below(No condensation)
- Size: 384*230*105(mm)
- Weight: 2.4KG
- Accessory: CD, AC power cord
