Control system Feedback control with PID
Desplay VFD
Speed range (RPM) 5 ~ 100
Accuracy at 100 RPM ±5
Max. load(Kg / lbs) 5 / 11.02
Material: PP (Polypropylene)+Silicone
Permissible ambient temperature (℃/℉) 5~60 / 41~140
Overall (W×D×H) (mm / inch) 276×320×150 / 10.87×12.6×5.91
Net weight (kg / Ibs) 3.7 / 8.16
Detail
Operating Features
- Microprocessor PID control
- Digital speed control providing gentle to vigorous motion
- Rocking shaker: 5 to 100 rpm - Easy to adjust tilt angle
- Rocking shaker: 7 ~ 13° - One-touch timer range: 1 min to 100 hr
Constructional Features
- Smooth, quiet, uniform, and yet powerful shaking motion
- Vivid and colorful vacuum fluorescent display (VFD) with touch-sensitive keypad.
- Compact and lightweight design allowing for use inside incubators, environmental chambers, refrigerators, cold rooms, etc.
- Three types of removable rubber mat for easy transport of well-plates, test tubes, etc.
(included Dimpled mat, and optional Rubber mat, Universal harness)
| Model | CRS-350 | |
| Control system | Feedback control with PID | |
| Desplay | VFD | |
| Shaking system |
Motion type | Rocking type |
| Speed range (RPM) | 5 ~ 100 | |
| Accuracy at 100 RPM | ±5 | |
| Tilt angle | 7 ~ 13° | |
| Max. load(Kg / lbs) | 5 / 11.02 | |
| Material | Dimpled mat (standard) | PP (Polypropylene)+Silicone |
| Body | PP (Polypropylene) | |
| Permissible ambient temperature (℃/℉) | 5~60 / 41~140 | |
| Dimensions | Tray (W×D) (mm / inch] | 276×276×10.87×10.87 |
| Overall (W×D×H) (mm / inch) | 276×320×150 / 10.87×12.6×5.91 | |
| Net weight (kg / Ibs) | 3.7 / 8.16 | |
| Electrical Requirements | AV 100 ~ 240 V, 50/60 Hz | |
| Cat. No. | KR Plug | AAH391115K |
| US Plug | AAH391115U | |
