JSEDM CNC-EB700L Electric Discharge Machine (400; 600 mm3/min)

Capacity of work tank: 1500x940x520mm

Work table size: 1000x600mm

Longitudinal travel(X-axis): 600mm

Cross travel(Y-axis): 450mm

Z axis travel(Z-axis): 400mm

Distance between platen to table: 350~750mm

Max. Electrode weight: 250kgs

Max. Work piece weight: 3000kgs

Fluid tank capacity: 1100L

Machine outside dimensions(WxDxH): 2850x2700x2610mm

Machine weight: 3600kgs

Max. Machining current: 60A; 90A(Optional)

Max. Power input: 7KVA; 10KVA

Max. Machining rate(mm3/min): 400; 600

Min. Electrode wear ratio: 0.12%

Best surface / Ra: Ra 0.2μm

Min. D. R. O. resolution(mm): 0.001mm

Generator weight: 320 kgs
