KEYSIGHT AC6801B 基础型交流电源 (500VA, 310V, 2.5A)

• Phases: Single-phase

• Maximum output Power: 500 VA

• AC output mode:

Voltage range: 155 Vrms / 310 Vrms

Voltage setting accuracy 0.3%/0.25% full-scale

Maximum rms current: 5 A/2.5 A

Maximum peak current 15 A/7.5 A

Frequency 500 Hz

Measurements Voltage, current, power

• DC output mode:

Voltage range: 190 V/380 V

Max current: 4 A/2 A

Maximum instantaneous current: 12 A/6 A

Power capacity: 400 W

• I/O: LAN/LXI Core and USB; Optional: GPIB
