• Max Output Rating: 20V, 2A
• Ripple & Noise (20 Hz to 20 MHz): RMS 0.8 mV; RMS 2 mA
• Overvoltage protection (OVP): 0.35 V
• Command processing time: < 10 ms
• Accuracy 12 months (23 ºC ± 5 ºC)
Voltage 0.05% + 8 mV
Current 0.05% + 1 mV
• I/O interfaces: LAN (LXI Core) and USB 2.0 FS (TMC488)
• AC input: 230 V input (± 10%), 47 to 63 Hz, 200 VA
• Overall dimension (H x W x D): 2U, 1/4 rack (102 x 106 x 365 mm)
• Weight: 3.7 kg
