KIKUSUI PAV320-2.5 多开关直流电源 (320V/ 2.5A)

Input voltage: 100 VAC ~ 240 VAC, 50 Hz ~ 60 Hz, single phase

Output power: 800 W

Output voltage:  320 V

Output current: 2.5 A

Constant voltage (CV):

+ Setting range: 0 ~ 320 V

+ Setting accuracy: 0.05% of the output voltage + 0.05% of the rated output voltage

+ Ripple noise: 30 mVrms

+ Line regulation: 0.01% mV

+ Load regulation: 0.01% mV

Constant current (CC):

+ Setting range: 0 ~ 2.5 A

+ Setting accuracy: 0.2% of rated output current

+ Ripple noise: 1.5 mArms

+ Line regulation: 0.02% mA

+ Load regulation: 0.09% mA

Protection functions: Overvoltage, Overcurrent, Overheat, Power limit, ...

Interface: USB, RS232, RS485, LAN (optional)

Accessories: Setup Guide, Power code, output terminal M4 screws, output terminal cover, packing list, safety information, CD-ROM, Quick Reference,...


Details

Datasheet


Manual
