Specifications
Flow range (mL/min): 0.4-13 L/min
Speed range (rpm): 30-600
Speed resolution (rpm): 1 rpm.
Flow accuracy: 3%
Power supply: AC 220V ± 10% 50Hz/60Hz; AC 110V ± 10% 50Hz/60Hz
Power consumption: < 400W
External control: Input level 5V, 12V (standard), 24V (optional)
Communication interface: RS485 MODBUS interface
Operating condition: Temperature 0~40°C; Relative humidity < 80%
IP grade: IP31
Dimensions (L x W x H): 340 x 235 x 175 mm (13.4 x 9.3 x 6.9 inch)
Weight: 13 kg (28.7 lbs)
Chi tiết
| Drive type | Pump head | CH | Tubing size (mm) | Flow rate (L/min) per channel |
| WG600S (304SS) | YZ35 | 1 | 73# 82# | 0.4- 13 |
| 2 x YZ35 | 2 | 73# 82# | 0.4- 13 |
