Leaptronix PLA-1016 PC逻辑分析仪

  • 制造商: LEAPTRONIX
    Model: PLA-1016
    • 报价要求 报价要求
  • 7,050,000 VND
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




  • 质量承诺
  • 正品保修
  • 送货到家
  • 交易简单化

manufacturer: Leaptronix

Model: PLA-1016

详细

Datasheet

PC-based Logic Analyzer & Data Logger
Provide the most economical measurement solution


Introduction

The PLA series provides complete date acquisition system, Logic Analyzer and Data Logger. This small instrument is making digital software and hardware designers the ability to quickly capture the complex signals for analysis and debugging. Moreover, the PLA is able to cooperate with your own design program for test automation system.



Features

Logic Analyzer
  • Internal (asynchronous) and External (synchronous) capture : Offer a more convenient environment for engineers.
  • The timing of each trigger point can be shown by the cursor mark.
  • Binary code and hexadecimal List mode (State) display.
  • Able to save measuring data and waveform results.
  • Provide I2C, SPI, UART and CAN signal decoding function on PC.
  • Provide various signal trigger and capture : Total of four kinds of trigger modes including Pattern/Edge/AND/OR.
  • 256K Bytes ~ 2M Bytes long memory depth : each CH memory depth is up to 128Kbits ~ 512Kbits.
  • The adjustable sample rate size can be set by users, which avoids long capturing time.
  • “Trigger Counter” and “Pulse Width Trigger” function.
  • High-speed Zoom In/Zoom Out function.
  • Smart software provides text file for saving the Binary Code of waveform.
  • USB 2.0 interface for PC link function, which can connect with PC for user to save, analyze, view and printout.
  • Powered by USB.
Data Logger
  • Provide friendly software, no matter what program language, just key in the timing,trigger condition and logic level etc, then start the data acquisition.
  • Use binary for logging the code.
Specification



PLA-1016

PLA-2532

Timing Analysis

100MHz

250MHz

State Analysis

100MHz

100MHz

Bandwidth

100MHz

100MHz

Channels

16CH

32CH

RAM Size

256K Bytes

2M Bytes

Storage Depth per Channel

128K bits x 16CH

512K bits x 32CH

Maximum Input Voltage

±30V

±30V

Threshold Range

-4V+4V

-4V+4V

Data Skew
(Channel to Channel)

10ns typical

4ns typical

PC Link Interface

USB 2.0

USB 2.0

Temperature

0℃~45

0℃~45

Dimension

15cm x 8cm x 3cm

15cm x 8cm x 3cm

Weight

230g

240g


PC System Requirement
  • Operating System:Windows 10 / 8 / 7 / Vista / XP ( 32bits & 64bits )
Standard Accessories
  • Main unit x1
  • Lead Set:16CH x1, 32CH x2
  • CD x1 (Driver and user manual are included)
  • USB cable x1
Optional Accessories
  • Testing probe (testing hook)
