Lisun LSG-1950 Goniospectroradiometer with Moving Mirror (0.001lx~99,999lx)

1) It is designed according to EN, IEC, GB, ECE, SAE and FMVSS108.

2) The accuracy of angle: 0.01° (LSG-1950), Resolution of angle: 0.001°

3) Luminosity Testing Range: Illuminance 0.001lx~99,999lx; Light Intensity 1.0cd~10^7cd(detector)

4) Accuracy of photometry: Class L

5) Testing Accuracy: 2%(Under Standard lamp); Stray Light: less than 0.1%

6) Can test max lamp to 35kg

7) English version software can run in WinXP or Win7/Win8/Win10


System Configuration:

A. Goniophotometric System

B. SLS-150W DC Standard Light Intensity Lamp

C. LS2012 Digital Power Meter

D. DC6010 CC & CV DC Power Source

E. CASE-19IN 19inch Standard Instruments Cabinet.
