Lisun UI9730 磁性材料分析仪

• Parameters to be measured (absolute value): Measure hypo-class U, Iout, Hz, Hc, Br, Bm, Hm, Br /Bm, μm, magnetic core loss, B-H curve, U curve and I curve

• Output capacity of the high frequency power: Uout: 1~300V, Iout: 0.05~5A, Pout: 300VA, frequency: 10~300kHz

• Accuracy: 2%

• With 12-bit high-speed A/D, sampling rate up to 40MHz, ensuring data precise and stable test result

• Supermaximal database, suitable for almost all kinds of magnetic material in market, such as: circle, E, U, ETD-EER, JAR, RM, EP, PM, EL, ER, PQ, EFD, plane E, etc

• Perfect software interface enables observation of curve in detail

• Meet international test requirements for magnetic particle ASTM E1444, ASTM E709-08, UL1993 S, UL6500
