Lisun WKS-8010 Medical Masks Synthetic Blood Penetration Tester (0~50KPa)
制造商: Lisun Model: WKS-8010 来源: China 保障: 12 Month - 报价要求
- 报价要求
- 联系
Pressure range: 0~50KPa
Accuracy: ±0.5%FS
Injection distance: 300mm±10mm adjustable
Nozzle diameter: 0.84mm
Injection pressure: 10.6 KPa（80 mmHg） 16 KPa（120 mmHg） 21.3 KPa（160 mmHg）
Injection speed: 450cm/s，550cm/s，635cm/s
Dimension: 825mm×440mm×335mm
Power supply: AC 220V，50Hz
Datasheet
Features
The instrument uses a gas source that can provide (20 ± 1) kPa pressure to continuously pressurize the sample without being limited by the space of the test site.
The instrument equipped with a pressure gauge to display the pressure, the pressure is adjustable.
Use pressurized medium: compressed air.
The special stainless steel penetrating test tank ensures a firm grip on the sample, and prevent synthetic blood from splashing around.
Square metal blocking net: Open space ≥50%; bending≤5mm at 20kPa.
Digital timer, accuracy: ±1s.
The instrument has a clamp that can generate 13.5Nm torque.
