Mahr 4150901 刻度盘比较器 (40F, 1 - 2", .00005")

Standard: Factory standard

Measuring range: 1 - 2"

Graduation value: .0001''

Error limit: .00008"

Parallelism deviation: .00008"

Flatness deviation: .00001"

Spindle diameter: 7.5 mm

Spindle pitch: .025"

Dial color: White

Type of dial face: 25-0-25

Dial comparator measuring range (measuring screw): ± .0025"

Dial comparator scale graduation value: .00005"

Measuring force: 9 N

Dial comparator error limit Ge: .00005"

Details

Dimensions: a 174 mm | b 125 mm | c 30 mm | d 85 mm | e 56 mm

Dimensional drawing 1
