Mahr 4154001KAL 刻度比较器 (40T, 25-50mm, 1 µm)

Standard: DIN 863-3

Measuring range: 25-50mm

Error limit: 2 µm

Parallelism error: 2 µm

Flatness deviation: 0.2 µm

Spindle pitch: 0.5mm

Graduation value: 1 µm

Measuring force: 6.5 N

Error limit Ge: 1 µm

Dimensions: a 52 mm | b 40 mm | c 4 mm | d 11 mm | e 8 mm |
