Mahr 4301300KAL 测试指示器 ( 800SGB. ± 0.5mm)

Measuring range: ± 0.5mm

Product type: 800SGB

Graduation value: 0.01 mm

Standard: Factory standard

Type of dial face: 50-0-50

Range per rev.: 1 mm

Span of error fe: 10 µm

Total span of error fges: 13 µm

Measuring value hysteresis fu: 4 µm

Partial measuring range ft: 5 µm

Repeatability fw: 3 µm

Measuring force: 0.07 N

Scale diameter: 38 mm

Dial color: Yellow

Dimensions: a 40.5 mm | c 31.4 mm | d 35.7 mm | e 93 mm | f 117 mm
