Mahr MarSurf LD 130 非球面测试台 (13mm/26mm)

Resolution: 0.8 nm

Start of traversing length (in X): 0.1 mm

End of traversing length (in X): 130 mm

Positioning speed: 0.02 mm/s - 200 mm/s

Measuring speed:0.02 mm/s - 10 mm/s;for roughness measurements

                0.1 mm/s - 0.5 mm/s is recommended

Measuring range mm: 13 mm (100 mm probe arm)

                    26 mm (200 mm probe arm)

Traversing lengths: 0.1 mm - 130 mm

Measuring force (N): 0.5 mN - 30 mN, software adjustable

Detail

Datasheer:
