MANNCORP 850 台式回流炉
制造商: MANNCORP Model: 850 - 联系
pplicable Solder Types
| Lead-Free and Leaded | |
| PCB Size (Max.) | 13" (330 mm) x 9.4" (240 mm) |
| Heating Method | Forced Hot Air Convection; Resistance Heaters |
| Min / Max Temperatures | Preheat stage: 50°C/230°C Reflow stage: 60°C/260°C |
| Temperature Control Method | PID Control; ±1.5% |
| Warm-up Time | 90°C/min |
| Programming | LCD Touchscreen |
| Power | 220 V, Single Phase, 50/60 Hz 1.5 KW; 4 KW (max.) |
| Air Supply | 60 psi (4 bar) |
| Dimensions | 27.4" L x 21.2" W x 16.1" H (695 mm L x 540 mm W x 410 mm H) |
| Weight | approx. 55 lbs. (25 Kg) |
