Memmert ONE10油热浴锅(10升)


Controllerdigital display (LED) of all set parameters, such as temperature and alarm values (0,1°C resolution) as well as time values
Timerdigital timer from 1 min. up to 999 hours for: ON (continuous operation), DELAYED ON, HOLD or HOLD set-temperature dependent with guaranteed holding time
Calibrationon controller
Temperature sensor2 Pt100 sensors Class A in 4-wire-circuit, mutually monitoring and taking over the performance at the same temperature value
Temperature controlmechanical temperature limiter TB protection class 1 switching the heating off at approx. 30°C above max. temperature of the bath
Temperature controlindependently working, electronic overtemperature temperature limiter TWB protection class 2
Temperature controlin case of overtemperature due to failure, the heating is switched off at approx. 10°C above the set temperature (fixed value)
Autodiagnostic systemfuzzy-supported PID microprocessor controller with integrated autodiagnostic system with fault indication

visual and acoustic alarm at programme end and as input acknowledgement as well as in case of low liquid level, heating is switched off automatically

Setting temperature range+20 to +200 °C
Working temperature rangemin. 5 above ambient up to +200 °C
resolution of display and setting accuracy0,1°C up to +99,9°C / 1°C from 100°C
Dimensions W x H x D in mmw(A) x h(C) x d(B): 350 x 140 x 210 mm
Interioreasy-to-clean interior, made of stainless steel, reinforced by deep drawn ribbing, material no. 1.4301 (ASTM 304), laser-welded
Volume10 l
Liquid level min.(H) 97 mm
Liquid level max.(I) 120 mm
