Dimensions: 1830 x 750 x 1020 mm / 6 x 2.5 x 3.4 ft
Table size: 1030 x 660 mm / 40 1/2 x 26 "
Maximum cutting width with parallel guide/rip fence: 300 mm / 11 3/4 "
Maximum cutting width with supplementary table: 1300 mm / 51 "
Maximum material width with mitre fence: 260 mm / 10 1/4 "
Cutting height: 127 - 127 mm // 5
Revolutions at rated load: 2750 rpm
Cutting speed: 58 m/s / 190 ft/s
Saw blade: 400 x 30 mm / 15 3/4 x 1.181 "
Mains voltage: 380 - 415 V
Rated input power: 4200 (S6 40%) W /
Output power: 3250 (S6 40%) W /
Weight: 88 kg / 194 lbs
Sound pressure level: 91 dB(A)
Sound power level (LwA): 109 dB(A)
Uncertainty of measurement K: 3.8 dB(A)
Carbide saw blade (28 teeth)
Table Length Extension
Parallel Guide / Rip Fence
Mitre fence with wedge type charge
Circular saw blades, Other accessories for semi-stationary/stationary saws
Robust machine with large cutting height for universal use on the construction site
Easy to use protective cover for safe working
High user protection thanks to splash-proofed switch and motor
Corrosion protection thanks to saw table made of galvanised sheet steel
Robust parallel guide/ripping fence with quick eccentric clamp
Push stick ready to use on parallel guide for increased safety
Retractable mitre fence with wedge type charge
More safety and durability thanks to motor brake and overload protection
Restart protection: prevents unintentional start-up after power supply interruption
Table length extension for long work pieces, foldable
High torque three-phase motor
