Dimensions: 790 x 515 x 515 mm / 2.6 x 1.7 x 1.7 ft
Support surface: 340 x 775 mm
Maximum cutting width 90°/45°: 305 / 205 mm // 12 / 8 1/16 "
Maximum cutting depth at 90°/45°: 92 / 47 mm // 3 5/8 / 1 13/16 "
Cutting capacity 90°/90°: 305 x 92 mm / 12 x 3 5/8 "
Cutting capacity 45°/45°: 205 x 47 mm / 8 1/16 x 1 27/32 "
Turntable setting left/right: 47 / 47 °
Saw blade tilt left/right: 47 / 2 °
Saw blade: 254 x 30 mm / 10 x 1.181 "
Rated input power S1 100%: 1450 W
Rated input power S6 20%: 1800 W
No-load speed: 4500 rpm
Revolutions at rated load: 3150 rpm
Cutting speed: 60 m/s / 197 ft/s
Weight: 16.3 kg / 36 lbs kg
Cable length: 2 m / 7 ft
Sound pressure level: 99 dB(A)
Sound power level (LwA): 106 dB(A)
Uncertainty of measurement K: 3 dB(A)
Carbide saw blade (48 teeth)
Tool for saw blade change
Chip Collection Bag
2 x Table length extensions
Circular saw blades, Other accessories for semi-stationary/stationary circular saws, Further accessories for crosscut and mitre saws, Further accessories for band saws, Other accessories for semi-stationary/stationary saws
Sliding function for wide work pieces.
Compact light weight, suitable also for one-handed transport
Robust die-cast aluminium design for the highest demands
Easy transport thanks to ergonomically-designed handles and saw head lock
Effective dust extraction via integrated dust scoop
Fast and precise setting of common angles using stop points
Laser for exact display of the cutting line (mains powered, no batteries required)
Adjustable and extendable table width extensions, removable to put long panels, slabs etc. underneath
Bright LED work light for illumination of the cutting line (mains powered, no batteries required)
Sliding high rear fence profiles for safe sawing
Material clamp for secure fixing of the work piece from the top or front
Depth guide for easy creation of grooves
Saw head can be inclined to the left, with additional angle range for undercuts
All scales and operating elements are visible from the working position and can be operated intuitively
Easy saw blade change by means of spindle lock: No dismantling of the pendulum guard required
