MITUTOYO SP25M 小型精密扫描探头

A complete set of SM25-2 and SH25-2

Measurement range: ±0.5mm

Max. permissible probing error during scanning: MPETHPʺ2.3 m (Crysta-Apex C700/900: If the ø4X50mm stylus is used.)

Spring rate: 0.4N/mm

Amount of over travel: ±2.0mm (XY) ±1.7mm (Z)

Max. stylus length: 200mm (When SM25-3 or SH25-3 is used.)

Stylus mount: M3

Max. scanning speed: 120mm/s [at a known geometry scanning]

Probe head: Essential: PH10M/PH10MQ

Applicable models: CNC coordinate measuring machines
