Driver type : Lever & Push-to-Start
Drive size: 1/4 F/Hex
Torque range: 4.3 - 17 lbf.in / 50 - 200 N.m
Adjustable RPM : 490 - 730 r/m
Size: Ø 1.5 inch x 9.25 inch
Weight: 15 oz / apprx 45 g
Remarks: other accessories can be optional on the datasheet.
Torque Ranges 0.9 - 17 lbf.in
Features a built-in screw counter. No external screw counter needed.
Detect and eliminate costly screw-fastening errors.
Detects cross threading, omissions, unfinished rundowns and cycle complete.
Detection of fastening error and buzzer alert.
Fastener accept and reject lights (Go/No Go).
Visual assembly fastener count (count up or down), including total count. Program fastening time.
High performance brushless motor design provides durability and reduces the standard maintenance cost for electric drivers.
Designed for high production environments at an affordable price.
Minimal heat build-up even when tool is operated continuously.
Ensures accuracy in fastening with precision automatic shut-off clutch once preset torque is achieved.
- BLG-4000X model: Lever Start
- BLG-5000X, model: Two-way Start System (Switchable between Lever Start and Push-to-Start)
Torque adjustment scale.
