NGI N23010-06-03 高精度多路可编程直流电源 (0~6V, 0~3A)

Voltage

Range: 0~6V

Setting Resolution: 0.1mV

Setting Precision (23±5℃): 0.6mV

Readback Resolution: 0.1mV

Readback Precision (23±5℃): 0.6mV

Ripple Noise: ≤2mVrms

Long-term stability: 80ppm/1000h

Temperature Coefficient: 25ppm/℃

Current

Range: 0~3A/ 0~1mA

Setting Resolution: 0.1mA/ 0.1μA

Setting Precision (23±5℃): 3mA/ 1μA

Readback Resolution: 0.1mA/0.1μA

Readback Precision (23±5℃): 3mA/ 1μA

Long-term stability: 100ppm/1000h

Temperature Coefficient: 30ppm/℃

Withstand Voltage (Output Relative to Earth): 1500VDC

Withstand Voltage (Channel to Channel): 500VDC

Operating Environment: Operating Temperature:0℃~40℃；Storage Temperature:-20℃~60℃；Altitude＜2000m；Relative Humidity:5%~90%RH(non-condensing)；Atmosphere Pressure:80~110kPa

Communication Interface: LAN/RS232/CAN

AC Input: Voltage:100~240V AC，Frequency:47Hz~63Hz，Current:≤8A@220V，≤14A@110V

Dimension: 132.5mm(H)*482.0mm(W)Within Handle*559.0mm(D)

Net weight: Approx. 17kg
