Probe Type: Single-Ended Passive
Measure Frequency: 400 MHz
Voltage Range: -60 V to 60 V
Measure Current: —
Attenuation: 10 X
Provides connectivity for PXI Oscilloscope, Oscilloscope Devices, and the VirtualBench All-In-One Instrument.
Oscilloscope Probes can conduct signals up to 2.5 GHz, 300 V, or 500 Arms, even in extreme environments. They offer fixed attenuation of 10X or 100X or switchable attenuation between 1X and 10X. Oscilloscope Probes are offered in several types, including single-ended and differential, active and passive, voltage and current.
