Novel XD-202 Biological Microscope (binocular,45 °,WF10×/22,48-75mm)

Optical System: Infinite Optical System

Viewing Head: Seidentopf Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary 48-75mm

Eyepiece: Ф30  Wide Field Eyepiece WF10×/22, Eyepiece Tube Diameter 30mm

Objective

Infinite Plan Achromatic Objective 4×/0.10 WD=22

LWD Infinite Plan Achromatic Phase Objective

• 10×/0.25  WD=6

• 20×/0.4   WD=3.1

• 40×/0.55  WD=2.2

Nosepiece: Backward Quintuple Nosepiece

Condenser: ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm)

Centering Telescope: Centering Telescope(φ30mm)

Phase Annulus: 10×, 20×, 40×Phase Annulus Plate (Adjustable)

Stage

• Plain Stage 230×170

• Glasse Insert

• Attachable Mechanical Stage, X, Y Coaxial Control, Moving Range 80×120mm

• Auxiliary Stage

• Terasaki Holder

• Petri Dish Holder φ38

• Petri Dish Holder φ54

Focusing System: Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm down 4.5mm

Illumination: 6V30W Halogen Lamp, Brightness Adjustable

Filter: Blue, Green and Ground Glass,Diameter 45mm
