Leeb probe types: D, DC, DL, C, D+15, E, G
Measuring range for steel: HV:230~940; HRC:20~70; HB:90~650. Tensile strength, MPa 370~1740
Measuring accuracy: HV:±3%HV; HRC:±1.5%HRC; HB:±3%HB
Indenter: Hardened ball (Leeb)
Measuring direction: Any direction 360°
Data storage: Limited only by the memory card
Communication: Upload data to PC and export as a spreadsheet (USB cable and software included )
Hardness scale: HRC, HB, HV, HRB, HS, HL, MPa
Materials: Dynamic (Leeb) pre-calibrated for steel, alloy steel, cast iron, stainless steel, aluminum, bronze, brass, copper, Additional custom materials for calibration.
Data display: Angle (Leeb), Single test result, Max, Min, Average of tests, Number of tests, Deviation, Var. coeff, Histogram, Signal and Smart Mode (Filter of incorrect measurements).
Indication: Color LCD display (320×240)
Operating environment: Temperature:-20°C~40°C; Humidity: 30%~80%R.H.
Power supply: DC 4,5V (3 pcs batteries AA)
Instrument dimensions: 160x75x30mm
Net weight: Approx. 0.3kg (Without probe)
Battery life: Approx. 10 hours.
Standard package: Hardness tester, Leeb probe, 3 batteries, Charger, USB cable, Operating manual, Software for PC, Case
Option Rockwell Hardness Test Block HRC (HRA orHRB): 160 USD
Option Brinell Hardness Test Blocks HB: 300 USD
Option Vickers Hardness Test Blocks HV: 240 USD
Option Leeb Hardness Test Block (type D): 320 USD
Option Leeb Hardness Test Block (type G): 800 USD
