Novotest T-U3 超声波硬度计(UCI探针)

UCI probe types: 1kgf (10N) 2.2 lbf, 5kgf (50N) 11lbf, 10kgf (98N) 22lbf
Measuring range: HV:230~940; HRC:20~70; HB:90~650. Tensile strength, MPa 370~1740
Measuring accuracy: HV:±3%HV; HRC:±1.5%HRC; HB:±3%HB
Measuring direction: Any direction 360°
Data storage: Limited only by the memory card
Communication: Upload data to PC and export as a spreadsheet (USB cable and software included )
Hardness scale: HRC, HB, HV, HRB, HS, HL, MPa
Materials: Pre-calibrated for steel, has calibration scales for additional custom materials
Data display: Load applied/contact (UCI), Single test result, Max, Min, Average of tests, Number of tests, Deviation, Var. coeff, Histogram, Signal and Smart Mode (Filter of incorrect measurements)
Indication: Color LCD display (320×240)
Operating environment: Temperature:-20°C~40°C; Humidity: 30%~80%R.H.
Power supply: DC 4,5V (3 pcs batteries AA)
Instrument dimensions: 160x75x30mm
Net weight: Approx. 0.3kg (without probe)
Batteries life: Approx. 10 hours
Standard package: Hardness tester, UCI probe, 3 AA batteries, Charger, USB cable, Operating manual, Case

Option Rockwell Hardness Test Block HRC (HRA orHRB): 160 USD
Option Brinell Hardness Test Blocks HB: 300 USD
Option Vickers Hardness Test Blocks HV: 240 USD
Option Leeb Hardness Test Block (type D): 320 USD
Option Leeb Hardness Test Block (type G): 800 USD

Detail

Datasheet

Option

Standard Set of Rockwell Test Blocks HRC (3 pc. In set)
Standard Set of Brinell Test Blocks HB (3 pc. In set)
Standard Set of Vickers Test Blocks HV (3 pc. In set)
Leeb Hardness Test Block (1 pc. In set)
