Ophir SP1201 激光功率热传感器 (900-1700nm)

Wavelengths: 900-1700nm

Beam Sizes: 300µm-7.4mm

Pixel spacing: 30μm square

Interface: GigE

Sensor Type: InGaAs

Compatible Light Sources: CW, Pulsed

Active Area: 9.6 x 7.6mm

Number of effective pixels: 320 x 256 (QVGA)

Dynamic range: 59dB

Frame Rate: 60Hz

Ambient operating temperature: -20° to 55° C

Dimensions: 55mm x 55mm x 78mm

Weight: 370 g (0.8 Ibs)

Compliance: CE, UKCA, China RoHS

BeamGage Professional (for USA only): BGP-GigE-SP1201
