PHYWE 13533-93 Power Supply (2~12VDC, 2~14VAC)

Function and Applications

Power supply unit for low  voltage supplies DC and AC voltages in 2 V steps.

Equipment and technical data

Galvanic isolation for all outputs, free-of-ground

Selection of voltage output via one side fixed 4 mm bridge plug

AC output: 2/4/6/8/10/12/14 V/5 A

DC output: 2/4/6/8/10/12/14 V/5 A

Max. current (short term): 10 A

Max. power: 75 VA

Fuses: 10 A

Supply voltage: 230 V AC

Dimensions (mm): 230 x 236 x 168
