PMS Air Trace 环境空气采样器(空气环境)

  • 制造商: PMS
    Model: Air Trace
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Applications
+ Pharmaceutical cleanroom monitoring for presence of microorganisms
+ Monitoring of aseptic filling areas, laminar flow workstations, and isolators
+ Compressed gases monitoring
+ Microbiological monitoring of surgical suites or operating rooms

Plate size 145 ± 5 mm diameter (75 ml fill)
Slit to agar distance 2.5 ± 0.5 mm (automatically adjusted by instrument during initial sampling)
Agar depth Min. = 5 mm; Max. = 9 mm
Flow rate 1 CFM (28.3 LPM) ± 10% tolerance
Flow rate control Automatic
Sample time Adjustable: 2 minutes to 5 hours (100% plate at 5 hours)
Rotation speed Min. = 1 revolution/5 hours; Max. = 1 revolution/2 minutes
Percent of plate exposed User-adjustable: Up to 100%
Sample exhaust HEPA filtered
Gas pressure Max. 5 bars (70 psi)
Communication RS-232C to serial printer
Dimensions (h, w, d) 9.4 x 10.2 x 15.4 in (24 x 26 x 39 cm)
Weight Air Trace Environmental: 28 lb (13 kg); Air Trace Compressed Gas version: 20 lb (9 kg)
Operating conditions Temperature: 50 – 95 °F (10 – 35 °C); Humidity: 10 – 85% (non-condensing)
Power:
100 – 240 VAC / 50 – 60 Hz, 200 W; (Air Trace Compressed Gas version only)
120 VAC / 60 Hz, 200 W; (Air Trace Environmental-120)
220 – 240 VAC / 50 Hz, 200 W; (Air Trace Environmental-240)
100 VAC / 50 Hz, 200 W; (Air Trace Environmental-100)
