- Detectors
+ Gamma-radiation detector: Geiger-Muller counter
+ Chemical warfare agent: Ion Mobility Spectrometry (IMS)
- Dose rate measuring range: -
- Dose rate accuracy (H - dose rate, µSv/h): -
- Dose measurement range: -
- Dose accuracy:-
- Dose rate threshold range: 0.001 up to 999 mSv/h
- Gamma radiation energy range: 0.06 – 3.0 MeV
- Energy response relative to 0.662 MeV (Cs-137): -
- Detection time of exceed threshold concentration
(at normal climatic conditions: temperature +20°
C ±5°C, atmospheric pressure 101.3 (+5.4; -17.3) kPa,
relative humidity 60 (+20; -30) %):
+ threshold for organophosphorous compounds detection 5*10-5mg/l,
no more than: 5 s
+ threshold for arsenic-containing compounds detection 5*10-4mg/l,
no more than: 15 s
+ threshold 3*10-4mg/l for arsenic-containing compounds, no more than:-
- Detection time of step increase or decrease of
gamma-radiation dose equivalent rate from 10 to
100 mSv/h, no more than: 10 s
-Power supply: two AA type batteries
- Batteries lifetime, not less than: 40 h
- Operating conditions
+ temperature range: -20 to +60°C (-4 to +140 °F)
+ relative humidity: up to 98% at 35°C (95°F)
+ pressure: from 84 to 106.7 kPa
-Case protection (non-operating condition): IP31
- Weight, not more than: 550 g (19.4 oz)
- Dimensions: 60 x 35 x 230 mm (2 3/8 x 1 3/8 x 9)
