Power 75W, 300W max
Current 15A / 60A max
Voltage 60V
PROTECTIONS
Over Power Protection(OPP) 105%
Over Current Protection(OCP) 105%
Over Voltage Protection(OVP) 105%
Over Temp Protection(OTP) yes
Constant Current Mode
Range: 0 ~ 1.5A/0~15A
Resolution 0.0254mA/0.25mAA
Accuracy 0.1%
Constant Resistance Mode
Range 4Ω-240KΩ/0.02Ω~4Ω
Resolution: 0.04166mS/0.0666mΩ
Accuracy ± 0.2%
Constant Voltage Mode
Range 0 ~ 6V/0~60V
Resolution 0.0001V/0.001V
Accuracy ± 0.05%
Constant Power Mode
Range 0 ~ 7.5W/0-75W
Resolution 0.000125W/0.00125W
Accuracy ± 0.5%
Constant Current + Constant Voltage Mode
Range 60V/15A
Resolution 0.001V/0.25mA
Accuracy 1%
Constant Power + Constant VoltageMode
Range 60V/75W
Resolution 0.001V/0.00125W
Accuracy 1%
Dimension(HxWxD): 143 x 108 x 412 mm
Current 15A / 60A max
Voltage 60V
PROTECTIONS
Over Power Protection(OPP) 105%
Over Current Protection(OCP) 105%
Over Voltage Protection(OVP) 105%
Over Temp Protection(OTP) yes
Constant Current Mode
Range: 0 ~ 1.5A/0~15A
Resolution 0.0254mA/0.25mAA
Accuracy 0.1%
Constant Resistance Mode
Range 4Ω-240KΩ/0.02Ω~4Ω
Resolution: 0.04166mS/0.0666mΩ
Accuracy ± 0.2%
Constant Voltage Mode
Range 0 ~ 6V/0~60V
Resolution 0.0001V/0.001V
Accuracy ± 0.05%
Constant Power Mode
Range 0 ~ 7.5W/0-75W
Resolution 0.000125W/0.00125W
Accuracy ± 0.5%
Constant Current + Constant Voltage Mode
Range 60V/15A
Resolution 0.001V/0.25mA
Accuracy 1%
Constant Power + Constant VoltageMode
Range 60V/75W
Resolution 0.001V/0.00125W
Accuracy 1%
Dimension(HxWxD): 143 x 108 x 412 mm
